Key features:

 Up to 4ch 1080P IP cameras access.

 Easy to use Same Interface of GUI/WEB/Client.

 1 SATA hard disk up to 6TB.

1 RJ45 10M/100M network interface.

 4ch POE ports.

 Simultaneous HDMI&VGA up to 1080P output.

 2 x 2.0 USB Host.

 Smart1U.

VIDEO/AUDIO INPUT :

-Video Input 4ch 6MP/5MP/4MP/3MP/1080P/720P;

-Incoming Bandwidth 40Mbps ,(main stream 32Mbps ,sub stream 8Mbps);

-Outgoing Bandwidth Total 80Mbps;

-Audio Input G711_A/G711_U.

VIDEO/AUDIO:

-OUTPUT Recording Resolution: 6MP/5MP/4MP/3MP/1080P/960P/720P/D1VGA/CIF/QCIF.

-Frame Rate 6MP/5MP/4MP/3MP@15fps; 1080P@25fps(PAL),30fps(NTSC).

-Live View/Playback Resolution 6MP/5MP/4MP/3MP/1080P/960P/720P/D1VGA/CIF/QCIF.

-Live View/Playback Capacity 4ch 1080P/720P/D1,1ch 6MP/5MP/4MP.

-HDMI/VGA Output 1920x1080/60Hz,1280x720/60Hz,1024x768/60Hz.

-Audio Output N/A .

HARD DISK :

-SATA HDD 1 SATA interface for 1HDD.

-Mounting Mode Embedded.

-Capacity Up to 6TB for each disk.

NETWORK :

-Network Interface 1 RJ45 10M/100M.

-network interface Protocol RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,NTP.

-POE Interface 4ch 100Mbps ,IEEE802.3af..

-POE Max Power 36W.

INTERFACE :

-/VGA 1ch HDMI, 1ch VGA.

-USB USB 2.0 x2 .

-Audio I/O N/A.

-Alarm I/O N/A.

-Reset Button Yes.

GENERAL:

-Power Supply DC 48V –DC52V,Max Input 70W.

-Power Consumption Max 10W(without HDD,USB,POE).

-OperatingTemperatur e -10° C ~ 45° C (14° F ~ 113° F ).

-Operating Humidity 0% - 90% RH.

-Chassis Smart 1U.

-Product Dimensions 255x235x47.5mm.

-Product Weight 930g .
